QSC8.3QUANTUM系列發動機 |
額定功率: |
405kw |
額定轉速: |
3000rpm |
缸徑: |
114mm |
沖程: |
135mm |
排量: |
8.3L |
配置: |
D413038MX03 |
進氣方式: |
Turbocharged/Sea Water Aftercooled |
最大扭矩: |
1799N.M(轉速為1800rpm下的最大扭矩) |
壓縮比: |
16.3 |
額定扭矩: |
1289N.M |
廢氣排溫: |
483℃(Turbine out)/666℃(Manifold) |
廢氣體積流量: |
1253L/S |
噪聲等級: |
82~98dBA@1m |
平均效應壓力: |
1958kPa(Brake) |
點火順序: |
1-5-3-6-2-4 |
活塞速度: |
13.5m/s |
燃油系統: |
HPCR |
冷卻系統: |
水冷 |
排放標準: |
EPA Tier 3-Model year requirements of the EPA marine regulation(40CFR1042); IMO Tier II-Tier2(Two)NOx requirements of International Maritime Organization(IMO),MARPOL 73/78 Annex VI,Regulation 13;RCD-meets the requirements of the recreational Craft Directive 94/25/EC as amended by 2003/44/EC in accordance with ISO 8178-1 |
|
|
